Automatic Double-Sided Glass Chamfer Machine

Technical Specifications:

• Voltage Input: 220V, 50Hz, single-phase

• Rated Power: 0.37kW × 2

• Rated Air Pressure: 0.4–0.6 MPa

• Weight: Approx. 280 kg

• Dimensions: 1420mm(L) × 750mm(W) × 1520mm(H)

• Clamping Spindle Speed: 30–50 rpm

• Grinding Wheels: 2 pieces (plus additional 2 pieces)

• Grinding Wheel Spindle Speed: 960 rpm

• Grinding Disc Size: 160–180 mm

• Workpiece Diameter: 52–100 mm

• Processing Time: 1–55 seconds

• Processing Tolerance: ±0.04 mm

• Workpiece Thickness: 1–8 mm

Machine Purpose:
This equipment is specifically designed for chamfering the circular profiles of brittle and hard materials, including glass, quartz, K-material, sapphire, ceramic, jade, metal, etc.

Structural Features:

1. Smart Control: Equipped with a hidden touchscreen interface for user-friendly operation and digital management.

2. Dual-Wheel Efficiency: Features front and rear grinding wheels, enabling simultaneous dual-side chamfering of circular workpieces through digital parameter settings. Enhances chamfer dimensional stability, surface finish, and reduces production costs compared to traditional manual single-side chamfering.

3. Multi-Mode Programming: Utilizes diamond and sintered grinding wheels. Motion is PLC-programmed to independently configure dual-wheel synchronous dual-side chamfering or single-wheel single-side chamfering modes.

4. Water-Protected Surface Design: Stainless steel water tank integrated into the workpiece platform submerges products during processing to prevent surface scratches.

5. Precision Clamping: Employs mechanical finger grippers to securely hold both ends of the workpiece, ensuring stable and reliable processing.
